2LB2MB 65° 17/17.5dBi Multi-band Antenna
Model: U2L2PX309.10P-V2-2C
Electrical Specifications
Frequency Range (MHz): | 698-960(R1,R2) | 1710-2690(Y1,Y2) | ||||
698-806 | 806-880 | 880-960 | 1710-2170 | 2300-2490 | 2490-2690 | |
Gain (dBi): | 15.3±0.5 | 15.8±0.5 | 16.3±0.5 | 16.0±0.5 | 17.0±0.5 | 16.8±0.5 |
Return Loss (dB): | >14 (VSWR<1.5) | |||||
Polarization: | ±45° | |||||
Horizontal 3dB Beamwidth (°): | 69 | 64 | 60 | 69 | 62 | 58 |
Vertical 3dB Beamwidth(°): | 8.5 | 7.0 | 6.5 | 7.5 | 6.0 | 5.3 |
Electrical Downtilt (°): | 2-12 Independently Continuously Adjustable | |||||
1st Upper Sidelobe Suppression (dB): | 15 | 15 | 15 | 15 | 15 | 15 |
Front to Back Ratio (dB): | 22 | 23 | 24 | 25 | 25 | 25 |
Cross Polar Ratio 0°(dB): | 15 | 15 | 15 | 15 | 15 | 15 |
Intraband Isolation (dB): | >25 | |||||
Interband Isolation (dB): | >25 | |||||
Average power tolerance (W): | 250 | 200 | ||||
Intermodulation IM3 (dBc): | <-150 (2×43 dBm) | |||||
Impedance (ohm): | 50 | |||||
Lightning Protection: | DC Grounded | |||||
Connector Type: | 8×4.3-10 Female | |||||
Mechanical Data
Antenna Dimensions (mm): | 2250×448×185 |
Packing Dimensions (mm): | 2520×535×280 |
Antenna Net Weight/bracket (kg): | 32.5 / 5.9 |
Antenna Gross Weight (kg): | 44.5 |
Radome Material: | Fiberglass |
Pipe OD (mm): | 50-115 |
Mounting Kits (Included): | BA.K.04.00069291, Adjustable Downtilt 0°-8° |
