1LB1MB 65° 14/17dBi 2 Ports Multi-band Antenna

698-806

806-880

880-960

1710-2170

2300-2490

2490-2690

Gain (dBi):

13.2±0.5

13.6±0.5

14±0.5

15.5±0.5

16.4±0.5

16.8±0.5

Return Loss (dB):

>14 (VSWR<1.5)

Polarization:

±45°

Horizontal 3dB Beamwidth (°):

69

65

62

68

62

58

Vertical 3dB Beamwidth (°):

17

15.5

14

7.5

6.0

5.5

Electrical Downtilt (°):

0-14

0-10

1^stUpper SidelobeSuppression (dB):

16

15

15

15

15

15

Front to Back Ratio (dB):

22

23

24

25

25

25

Cross Polar Ratio 0°(dB):

15

15

15

15

15

15

Intraband Isolation (dB):

>25

>28

Interband Isolation (dB):

>28

Max. Power Per Port (W):

250

200

Intermodulation IM3 (dBc):

<-150(2×43 dBm)

Impedance (ohm):

50

Lightning Protection:

DC Grounded

Connector Type:

2×4.3-10 Female

Packing Dimensions (mm):

1735×425×260

Antenna Net Weight/Bracket (kg):

16/ 5.9

Antenna Gross Weight (kg):

25.5

Radome Material:

Fiberglass

Pipe OD (mm):

50-114

Mounting Kits (Included):

BA.K.04.00069351 ,

Adjustable Downtilt 0°-16°
