1LB3MB 20°11/12/12/12dBi Stadium Antenna

698-800

800-960

1710-2200

2200-2700

Gain (dBi):

10.5±0.5

11.5±0.5

11±0.5

12±0.5

12±0.5

12±0.5

Return Loss (dB):

>14 (VSWR<1.5)

Polarization:

±45°

Horizontal 3dB beamwidth (°):

25±5

25±5

25±5

20±5

20±5

20±5

Vertical 3dB beamwidth (°):

65±8

65±8

60±8

60±8

60±8

60±8

Electrical Downtilt (°):

0 Fixed

Horizontal Sidelobe Suppression (dB):

≥18

≥18

≥18

≥18

≥18

≥18

Front to Back Ratio (dB):

≥25

≥25

≥25

≥25

≥25

≥25

Cross Polar Ratio 0° (dB):

≥17

≥17

≥17

≥17

≥17

≥17

Isolation Port to Port(dB):

≥23

Max. Power Per Port (W):

200

Intermodulation IM3 (dBc):

                              <-150 (2×43 dBm)

/

Impedance (ohm):

50

Lightning Protection:

DC Grounded

Connector Type:

6×4.3-10 Female
