1LB1MB 65° 8/11dBi 2 Ports Multi-band Antenna

698-806

806-880

880-960

1710-1920

1920-2170

2490-2690

Gain (dBi):

7.2±0.5

7.3±0.5

7.4±0.5

9.4±0.5

10.2±0.5

11.1±0.5

Return Loss (dB):

>14 (VSWR<1.5)

Polarization (°):

±45

Horizontal 3dB beamwidth (°):

70

68

67

70

65

58

Vertical 3dB beamwidth (°):

75

75

75

38

32

25

Electrical Downtilt (°):

0 Fixed

1^st Upper Sidelobe Suppression(dB):

15

Front to Back Ratio @180±30°(dB):

19

20

20

21

21

21

Cross Polar Ratio 0° (dB):

15

Cross Polar Ratio ±30° (dB):

11.0

10.0

7.5

7.0

6.0

0.0

solation Port to Port (dB):

>25

Power Rating (W):

100

100

Intermodulation IM3 (dBc):

<-150 (2×43 dBm)

Impedance (ohm):

50

Lightning Protection:

DC Grounded

Connector Type:

2×7/16 DIN Female

Packing Dimensions (mm):

507×420×253

Antenna Net Weight (kg):

3.51

Antenna Gross Weight (kg):

6.95

Radome Material:

PVC,UV Resistant

Pipe OD (mm):

70-114

Mounting Kits (Included):

BA.K.04.00033,horizontal adjustable -35°-+35°,vertical adjustable-45°-+45°
