Electrical Properties
88132005
Electrical Properties
| Characteristics Impedance (Ohm): | 50 |
| Frequency Range (GHz): | DC-6 |
| Insulation Resistance (MΩ): | ≥10000 |
VSWR: | ≤1.10@690-2700MHz |
| ≤1.12@2700-3700MHz | |
| ≤1.25@4800-5000MHz | |
| ≤1.30@5000-6000MHz | |
Insertion Loss (dB): | ≤0.10@690-960MHz |
| ≤0.15@1700-2700MHz | |
| ≤0.25@2700-3700MHz | |
| ≤0.25@4800-5000MHz | |
| ≤0.25@5000-6000MHz | |
| PIM (dBc): | ≤-155 |
| Durability (matings) (cycles): | ≥5000 |
